Pump series IPP3
Inlet pressure up to 40 bar
| Max. flow | 350 m³/h |
| Max. head | 70 m |
| Max. product viscosity | 1.000 cP |
| max. motor power | 45 kW |
The IPP3 pump series
The Packo stainless steel pumps of the IPP3 series are pumps made of solid, machined stainless steel 316L and are extremely suitable for high system pressure applications up to 40 bar.
- Fully machined stainless steel, solid design
- Large seal cavity to clean mechanical seal properly
- Monobloc execution with std. IEC motor
Application areas
The Packo high pressure pumps of the IPP3 series are used primarily in the reverse osmosis (RO) applications for the filtration of, for example, contaminated CIP-water, whey, etc. They are also used as a booster pump in a variety of skids.
You will find them in just about all industries including the dairy industry, breweries, beverage industry as well as in water treatment industry.
Your advantages
- Suitable for system pressure applications up to 40 bar
- High pump efficiency resulting in lower energy consumption
- Low NPSH values: less risk on cavitation
- Electropolished: easy to clean
- Easy construction and easy maintenance: less downtime
- Standard components
- Easy to install
- 1 mechanical seal diameter for the entire range
Technical information
| Performance | |
| max. flow rate | 350 m³/h |
| max. differential head | 70 m |
| max. inlet pressure | 40 bar |
| max. liquid viscosity | 1000 cP |
| max. temperature | 140°C |
| impeller type | closed |
| max. free passage | 17 mm |
| max. motor power | 45 kW |
| max. speed | 3000/3600 rpm |
| available frequency | 50/60 Hz |
| Specifications | |
| materials wetted parts | stainless steel 316L or similar |
| mechanical seal configuration | single balanced, quench, double seal |
| available O-ring material | EPDM, FKM, FEP-FKM, FFKM, Silicone |
| connections | flanges according to EN1092-1/11 PN40, Tri-Clamp fittings, etc. |
| surface finish | industrial, internal welds not hand polished, electropolished |
| certificates & legislation |  |
